12
Reference
Designator
Description Part Number Note
C917 33nF, X7R, 0402, 16V, 5% 296732-333 4
C919 220, COG, 0603, 50V, 5% 188454-221 4
C920 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C921 68pF, COG, 0402, 50V, 5% 268364-680 4
C922 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C923 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C924 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C925 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C1000 47pF, 0603, X7R, 50V, 10% 191470-470 4
C1001 47pF, 0603, X7R, 50V, 10% 191470-470 4
C1002 0.1, X7R, 0603, 50V, 10% 191470-104 4
C1004 X7R, 1206, 10%, 2.2, 16V, OPN 283163-225 4
C1005 .01uF, 0603, X7R, 50V, 10% 191470-103 4
C1006 TVS, ESD SUPPRESSOR, LOW
CAP
286375-001 4
C1007 1500pF, 0603, X7R, 50V, 10% 191470-152 4
C1100 22pF, 0603, COG, 50V, 5% 188454-220 4
Reference
Designator
Description Part Number Note
Q400 XSISTOR, BPLR, N, 40V, 200mA,
SOT23
146819 4
Q401 XSISTOR, BPLR, N, 40V, 200mA,
SOT23
146819 4
Q402 XSISTOR, BPLR, N, 40V, 200mA,
SOT23
146819 4
Q405 XISTOR, MOSFET, N-CH, 100V,
1.7A
312197-001 4
Q406 TRANSISTOR, MOSFET, N-CH, 2.5V 302882-001 4
Q407 XSISTOR, BPLR, N, 40V, 200mA,
SOT23
146819 4
Q600 XSISTOR, BPLR, N, 50V, 100mA,
SOT23
146817 4
Transistors
Reference
Designator
Description Part Number Note
FB1000 330 OHM, BEAD, FERRITE,
BLM18P, 0603
302257-331 4
FB1001 330 OHM, BEAD, FERRITE,
BLM18P, 0603
302257-331 4
FB1002 330 OHM, BEAD, FERRITE,
BLM18P, 0603
302257-331 4
FB1003 330 OHM, BEAD, FERRITE,
BLM18P, 0603
302257-331 4
FB1004 330 OHM, BEAD, FERRITE,
BLM18P, 0603
302257-331 4
FB1005 330 OHM, BEAD, FERRITE,
BLM18P, 0603
302257-331 4
FB1006 330 OHM, BEAD, FERRITE,
BLM18P, 0603
302257-331 4
FB1007 330 OHM, BEAD, FERRITE,
BLM18P, 0603
302257-331 4
FB200 330 OHM, BEAD, FERRITE,
BLM18P, 0603
302257-331 4
FB201 120 OHM, BEAD, FERRITE, 0402,
0.3A
324216-121B 4
FB202 120 OHM, BEAD, FERRITE, 0402,
0.3A
324216-121B 4
FB203 120 OHM, BEAD, FERRITE, 0402,
0.3A
324216-121B 4
FB204 120 OHM, BEAD, FERRITE, 0402,
0.3A
324216-121B 4
FB205 120 OHM, BEAD, FERRITE, 0402,
0.3A
324216-121B 4
FB206 120 OHM, BEAD, FERRITE, 0402,
0.3A
324216-121B 4
FB207 120 OHM, BEAD, FERRITE, 0402,
0.3A
324216-121B 4
FB208 120 OHM, BEAD, FERRITE, 0402,
0.3A
324216-121B 4
FB209 120 OHM, BEAD, FERRITE, 0402,
0.3A
324216-121B 4
FB600 FERRITEBD, IND0603, 200MA
330OHM
268373-331 4
FB700 220 OHM, BEAD, FERRITE, 0603,
2A
322644-221A 4
FB701 220 OHM, BEAD, FERRITE, 0603,
2A
322644-221A 4
FB800 220 OHM, BEAD, FERRITE, 0603,
2A
322644-221A 4
FB801 120 OHM, BEAD, FERRITE, 0603,
200mA
324058-121A 4
FB900 330 OHM, BEAD, FERRITE,
IND0603, 200MA
268373-331 4
ELECTRICAL PART LIST
DSP PCB Assembly
Reference
Designator
Description Part Number Note
U200 IC, Stereo ADC, 24-Bit, 192kHz 307160-001 4
U201 IC, OP-AMP, DUAL, SOIC-8, TLC-
2272
174989 4
U202 IC, OP-AMP, DUAL, SOIC-8, TLC-
2272
174989 4
U300 IC, DAC, 24-bit, 192kHz, 6-ch, 20-P 309061-001 4
U400 IC, I-MODE PWM CONTROLLER 312199-001 4
U401 IC, VOLT REG, ADJ., 500MA, DPAK 258496-001 4
U600 IC, RESET, SOT-23, MAX809, 2.63V 191158-06 4
U601 IC, INVERTER, SMD 266582-001 4
U603 IC, DSP, TMS320DA705, MASKED 289857-7051 4
U800 IC, CPLD, w/ 570FF, JTAG , 144-P 307343-002 4
U801 IC, SERIAL, FLASH, 3.3V, 32Mbit,
SO-8W
323017-032W 4
U802 IC, SECURITY, APPLE, 2.0B, C6 309630-006 4
U900 IC, uC, 3.6V, 64-pin, TQFP 307303-001 4
U901 IC, REST, 1.60V-4.63V, SC-70,
MAX803
319732-293
VR400 IC, VREG, LDO, ADJ, 1A, 1.5 to
5.5V, 8-P
324229-5500 4, 3
VR401 IC, Vreg, POS., LDO, .5A, ADJ._V 312828-002 4
VR402 IC, Vreg, POS., LDO, .5A, ADJ._V 312828-002 4
Diodes
Reference
Designator
Description Part Number Note
D1000 DIODE, SOT-23, BAV 99 147239 4
D1001 DIODE, SOT-23, BAV 99 147239 4
D1002 DIODE, SOT-23, BAV 99 147239 4
D400 DIODE, SCHOTTKY, 40V, 3A, SMB 193847-001 4
D401 DIODE, SCHOTTKY, 40V, 3A, SMB 193847-001 4
D402 DIODE, SCHOTTKY, 40V, 3A, SMB 193847-001 4
D403 DIODE, SCHOTTKY, 40V, 3A, SMB 193847-001 4
D405 DIODE, SOT-23, BAV 99 147239 4
ZR1000 DIODE, ZEN, 3.6V, 225MW, 5%,
SOT-23
135247-5227 4
ZR400 DIODE, ZEN, 5.1V, 225MW, 5%,
SOT-23
135247-5231 4
ZR401 DIODE, ZEN, 10.V, 225MW, 5%,
SOT-23
135247-5240 4
ZR402 DIODE, ZEN, 5.1V, 225MW, 5%,
SOT-23
135247-5231 4
Integrated Circuits
Capacitors (continued)
Inductors
To Next Page
