12
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description Part Number Note
R801 10.0K, 0402, 63MW, 1% 268361-1002
R802 10.0K, 0402, 63MW, 1% 268361-1002
R1000 3.32K, 0402, 63MW, 1% 268361-3321
R1001 3.32K, 0402, 63MW, 1% 268361-3321
R1002 49.9 OHM, 0402, 63MW, 1% 268361-49R9
R1003 56.2K, 0402, 63MW, 1% 268361-5622
R1004 100 OHM, 0402, 63MW, 1% 268361-1000
R1005 100 OHM, 0402, 63MW, 1% 268361-1000
R1006 100 OHM, 0402, 63MW, 1% 268361-1000
R1007 100 OHM, 0402, 63MW, 1% 268361-1000
R1008 100 OHM, 0402, 63MW, 1% 268361-1000
R1009 100 OHM, 0402, 63MW, 1% 268361-1000
R1010 100 OHM, 0402, 63MW, 1% 268361-1000
R1011 100 OHM, 0402, 63MW, 1% 268361-1000
R1014 100 OHM, 0402, 63MW, 1% 268361-1000
R1015 100 OHM, 0402, 63MW, 1% 268361-1000
R1016 100 OHM, 0402, 63MW, 1% 268361-1000
R1100 3.32K, 0402, 63MW, 1% 268361-3321
R1101 3.32K, 0402, 63MW, 1% 268361-3321
R1102 100K, 0402, 63MW, 1% 268361-1003
R1103 100K, 0402, 63MW, 1% 268361-1003
R1104 1.0M, 0402, 63MW, 1% 268361-1004
R1105 1.0M, 0402, 63MW, 1% 268361-1004
R1106 1.0M, 0402, 63MW, 1% 268361-1004
R1107 100K, 0402, 63MW, 1% 268361-1003
R1108 100K, 0402, 63MW, 1% 268361-1003
R1111 4.7 OHMS, 0402, 0.063W, 1% 268361-4R70
R1112 1.00K, 0805, 1/10W, 5% 133626-1025
R1113 499 OHMS, 0805, .125W, 1% 133625-4990
R1114 4.7 OHMS, 0402, 0.063W, 1% 268361-4R70
R1115 4.7 OHMS, 0402, 0.063W, 1% 268361-4R70
R1201 100 OHM, 0402, 63MW, 1% 268361-1000
R1202 100 OHM, 0402, 63MW, 1% 268361-1000
R1206 100 OHM, 0402, 63MW, 1% 268361-1000
R1207 100 OHM, 0402, 63MW, 1% 268361-1000
R1208 100 OHM, 0402, 63MW, 1% 268361-1000
R1210 100 OHM, 0402, 63MW, 1% 268361-1000
R1300 10.0K, 0402, 63MW, 1% 268361-1002
R1301 0 OHM, JUMPER, 0402 280043
R1303 100K, 0402, 63MW, 1% 268361-1003
R1304 100K, 0402, 63MW, 1% 268361-1003
R1306 215K, 0402, 0.063W, 1% 268361-2153
R1307 100K, 0402, 63MW, 1% 268361-1003
R1308 23.7K, 0402, 63MW, 1% 268361-2372
R1309 10.0K, 0402, 63MW, 1% 268361-1002
R1310 10.0 OHM, 0402, 63MW, 1% 268361-10R0
R1313 100K, 0402, 63MW, 1% 268361-1003
