Bose SoundTouch Service Manual

11
Wi-Fi Module PCB Assembly
Resistors (continued)
ELECTRICAL PART LIST
Reference
Designator
Description Part Number Note
R550 56.2K, 0402, 63MW, 1% 268361-5622
R551 100 OHM, 0402, 63MW, 1% 268361-1000
R552 100 OHM, 0402, 63MW, 1% 268361-1000
R553 56.2K, 0402, 63MW, 1% 268361-5622
R554 56.2K, 0402, 63MW, 1% 268361-5622
R555 1.50K, 0402, 63MW, 1% 268361-1501
R560 56.2K, 0402, 63MW, 1% 268361-5622
R561 56.2K, 0402, 63MW, 1% 268361-5622
R562 100 OHM, 0402, 63MW, 1% 268361-1000
R564 100 OHM, 0402, 63MW, 1% 268361-1000
R565 100 OHM, 0402, 63MW, 1% 268361-1000
R566 100 OHM, 0402, 63MW, 1% 268361-1000
R600 4.53K, 0402, 0.063W, 1% 268361-4531
R602 4.53K, 0402, 0.063W, 1% 268361-4531
R606 100 OHM, 0402, 63MW, 1% 268361-1000
R607 10.0K, 0402, 63MW, 1% 268361-1002
R608 10.0K, 0402, 63MW, 1% 268361-1002
R609 10.0K, 0402, 63MW, 1% 268361-1002
R610 10.0K, 0402, 63MW, 1% 268361-1002
R611 100 OHM, 0402, 63MW, 1% 268361-1000
R612 100 OHM, 0402, 63MW, 1% 268361-1000
R613 100 OHM, 0402, 63MW, 1% 268361-1000
R614 100 OHM, 0402, 63MW, 1% 268361-1000
R615 10.0K, 0402, 63MW, 1% 268361-1002
R616 100 OHM, 0402, 63MW, 1% 268361-1000
R617 100 OHM, 0402, 63MW, 1% 268361-1000
R618 1.00K, 0402, 63MW, 1% 268361-1001
R619 10.0K, 0402, 63MW, 1% 268361-1002
R620 10.0K, 0402, 63MW, 1% 268361-1002
R621 10.0K, 0402, 63MW, 1% 268361-1002
R622 100 OHM, 0402, 63MW, 1% 268361-1000
R623 10.0K, 0402, 63MW, 1% 268361-1002
R657 100 OHM, 0402, 63MW, 1% 268361-1000
R661 3.32K, 0402, 63MW, 1% 268361-3321
R662 3.32K, 0402, 63MW, 1% 268361-3321
R665 10.0K, 0402, 63MW, 1% 268361-1002
R667 10.0K, 0402, 63MW, 1% 268361-1002
R668 100 OHM, 0402, 63MW, 1% 268361-1000
R669 100 OHM, 0402, 63MW, 1% 268361-1000
R674 100 OHM, 0402, 63MW, 1% 268361-1000
R675 100 OHM, 0402, 63MW, 1% 268361-1000
R676 100 OHM, 0402, 63MW, 1% 268361-1000
R688 100 OHM, 0402, 63MW, 1% 268361-1000
R700 10.0K, 0402, 63MW, 1% 268361-1002
R701 10.0K, 0402, 63MW, 1% 268361-1002
R702 10.0K, 0402, 63MW, 1% 268361-1002
R800 10.0K, 0402, 63MW, 1% 268361-1002

