Bose SoundTouch Service Manual

10
Wi-Fi Module PCB Assembly
Resistors (continued)
ELECTRICAL PART LIST
Reference
Designator
Description Part Number Note
R424 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R425 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R426 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R500 100 OHM, 0402, 63MW, 1% 268361-1000
R501 100 OHM, 0402, 63MW, 1% 268361-1000
R502 100 OHM, 0402, 63MW, 1% 268361-1000
R503 10.0K, 0402, 63MW, 1% 268361-1002
R504 100 OHM, 0402, 63MW, 1% 268361-1000
R505 100 OHM, 0402, 63MW, 1% 268361-1000
R506 10.0K, 0402, 63MW, 1% 268361-1002
R507 5.76K, 0402, 63MW, 1% 268361-5761
R508 4.75K, 0402, 0.063W, 1% 268361-4751
R509 100 OHM, 0402, 63MW, 1% 268361-1000
R510 100 OHM, 0402, 63MW, 1% 268361-1000
R511 4.53K, 0402, 0.063W, 1% 268361-4531
R513 10.0K, 0402, 63MW, 1% 268361-1002
R514 10.0K, 0402, 63MW, 1% 268361-1002
R515 10.0K, 0402, 63MW, 1% 268361-1002
R516 100 OHM, 0402, 63MW, 1% 268361-1000
R517 10.0K, 0402, 63MW, 1% 268361-1002
R518 100 OHM, 0402, 63MW, 1% 268361-1000
R519 100 OHM, 0402, 63MW, 1% 268361-1000
R520 100 OHM, 0402, 63MW, 1% 268361-1000
R521 100 OHM, 0402, 63MW, 1% 268361-1000
R522 56.2K, 0402, 63MW, 1% 268361-5622
R523 100 OHM, 0402, 63MW, 1% 268361-1000
R524 1.00K, 0402, 63MW, 1% 268361-1001
R525 10.0K, 0402, 63MW, 1% 268361-1002
R527 10.0K, 0402, 63MW, 1% 268361-1002
R528 100 OHM, 0402, 63MW, 1% 268361-1000
R529 10.0K, 0402, 63MW, 1% 268361-1002
R530 100 OHM, 0402, 63MW, 1% 268361-1000
R531 100 OHM, 0402, 63MW, 1% 268361-1000
R532 100 OHM, 0402, 63MW, 1% 268361-1000
R533 10.0K, 0402, 63MW, 1% 268361-1002
R534 10.0K, 0402, 63MW, 1% 268361-1002
R535 1.00K, 0402, 63MW, 1% 268361-1001
R537 100 OHM, 0402, 63MW, 1% 268361-1000
R538 10.0K, 0402, 63MW, 1% 268361-1002
R539 10.0K, 0402, 63MW, 1% 268361-1002
R540 301 OHM, 0402, 63MW, 1% 268361-3010
R541 301 OHM, 0402, 63MW, 1% 268361-3010
R544 100 OHM, 0402, 63MW, 1% 268361-1000
R546 100 OHM, 0402, 63MW, 1% 268361-1000
R547 100 OHM, 0402, 63MW, 1% 268361-1000
R548 100 OHM, 0402, 63MW, 1% 268361-1000
R549 56.2K, 0402, 63MW, 1% 268361-5622


Bose SoundTouch Specifications

General

Number of drivers	-
Number of speakers	1
Audio output channels	2.0 channels
Recommended usage	Universal
Remotely operated	Yes
Card reader integrated	No
Product type	Stereo portable speaker
Product color	Black
Product design	Other
Volume control	Digital
Impedance	- Ω
Frequency range	- Hz
RMS rated power	- W
Display	OLED
Depth (imperial)	2.5 \
Width (imperial)	9.8 \
Height (imperial)	5.8 \
Cables included	AC
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wireless
Power source type	Battery

Weight and Dimensions

Depth	64 mm
Width	249 mm
Height	147 mm
Weight	1448 g
