Bose SoundTouch Service Manual

9
ELECTRICAL PART LIST
Wi-Fi Module PCB Assembly
Resistors (continued)
Reference
Designator
Description Part Number Note
R220 10.0K, 0402, 63MW, 1% 268361-1002
R221 4.75K, 0402, 0.063W, 1% 268361-4751
R225 100 OHM, 0402, 63MW, 1% 268361-1000
R229 100 OHM, 0402, 63MW, 1% 268361-1000
R240 10.0K, 0402, 63MW, 1% 268361-1002
R242 10.0K, 0402, 63MW, 1% 268361-1002
R243 10.0K, 0402, 63MW, 1% 268361-1002
R244 10.0K, 0402, 63MW, 1% 268361-1002
R245 10.0K, 0402, 63MW, 1% 268361-1002
R246 0 OHM, JUMPER, 0402 280043
R247 33 OHM, 0402, 1/16W, 1% 268361-33R0
R276 10.0K, 0402, 63MW, 1% 268361-1002
R279 0 OHM, JUMPER, 0402 280043
R280 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R281 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R282 0 OHM, 0402 ARRAY, 4CONVEX, 0.5
A
357537-0020
R283 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R284 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R285 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R286 0 OHM, 0402 ARRAY, 4CONVEX, 0.5
A
357537-0020
R287 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R288 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R289 0 OHM, 0402 ARRAY, 4CONVEX, 0.5
A
357537-0020
R290 0 OHM, 0402 ARRAY, 4CONVEX, 0.5
A
357537-0020
R300 100 OHM, 0402, 63MW, 1% 268361-1000
R302 1.00K, 0402, 63MW, 1% 268361-1001
R304 100 OHM, 0402, 63MW, 1% 268361-1000
R305 100 OHM, 0402, 63MW, 1% 268361-1000
R307 10.0K, 0402, 63MW, 1% 268361-1002
R308 10.0K, 0402, 63MW, 1% 268361-1002
R309 10.0K, 0402, 63MW, 1% 268361-1002
R311 100 OHM, 0402, 63MW, 1% 268361-1000
R400 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R401 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R402 243 OHMS, 0402, 63MW, 1% 268361-2430
R403 10.0K, 0402, 63MW, 1% 268361-1002
R404 10.0K, 0402, 63MW, 1% 268361-1002
R406 49.9 OHM, 0402, 63MW, 1% 268361-49R9
R407 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R408 100 OHM, 0402, 63MW, 1% 268361-1000
R409 10.0K, 0402, 63MW, 1% 268361-1002
R413 806 OHM, 0402, 63mw, 1% 268361-806R
R414 1.00K, 0402, 63MW, 1% 268361-1001
R415 33 OHM, 0402, 1/16W, 1% 268361-33R0
R421 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R422 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R423 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4

