6
English
Setting Up
Installing the battery
The 9-volt battery maintains clock and alarm settings and operates the Wave
®
radio/CD’s
backup alarm system for up to 24 hours, during a power loss or while the system is tempo-
rarily unplugged. Operating without this battery leaves the memory unprotected, but will not
harm the product.
Use a standard 9V battery (IEC 6F22 in Europe), available at most retail stores. Use an
alkaline battery for longer backup time.
Note:
The battery does not provide power for Wave
®
radio/CD operation or for the display.
CAUTION:
Do not remove the tape from the top front of the system. It prevents the CD door
from opening accidentally when you turn the system over.
1. Carefully turn your system upside down.
2. Locate the battery compartment on the bottom (Figure 2).
3. Press the arrow on the cover to slide the compartment open.
4. Match the large (–) terminal on the battery to the small terminal on the clip (which lifts out
of the compartment for easier connection).
5. Snap the terminals together firmly.
6. Slide the cover closed.
Note:
Now is a good time to record the serial number found on the bottom of your system.
Write it on your warranty card and in the space provided on page 3.
7. Turn the system right side up.
8. Remove the tape from the top front of the system.
CAUTION:
After you remove the tape, be sure to remove any CD in the sytem
before
turning the system over again. With no tape in place, the CD cover opens freely whenever
the system is turned upside down, so a CD could fall out and be damaged.
Figure 2
Installing the battery
–+
