Boss AD-3 - Panel Descriptions; Top Panel Controls; Rear Panel Connections; Foot Pedals

fig.1
POWER
Indicator
ANTI-FEEDBACK Knob
BOTTOM Knob
TOP Knob
2 x 2 CHORUS Knob
REVERB Knob
PEAK
Indicator
ANTI-FEEDBACK AUTO Pedal
CHORUS Pedal
Pedal
Indicator
Pedal
Indicator
INPUT Jack
INPUT LEVEL Knob
OUTPUT SELECT Switch
OUTPUT Jack L, R
POWER Switch
AC Adaptor Jack
Cord Hook
