Boss DS-1 User Manual

4
PANEL DESCRIPTIONS
1. AC Adaptor Jack
Accepts connection of an AC Adaptor (op-
tionally available BOSS PSA-Series). By
using an AC Adaptor, you can play without
being concerned about how much battery
power you have left.
* You may find that it is a good idea to keep a
battery installed in the unit even while using
an adaptor. That way your playing won't be
disrupted even if the adaptor is accidentally
disconnected.
* If you are going to use an AC adaptor, be sure
to use the specified unit (BOSS PSA-Series).
Use of any other adaptor may result in dam-
age, malfunction or electric shock.
Also, if you are not going to be using it for an
extended period of time, disconnect the AC
adaptor from the AC outlet.
1
2
3
4
5
6

Boss DS-1 Specifications

General

Effect Type	Distortion
Controls	Level, Tone, Distortion
Bypass	Buffered Bypass
Input Impedance	470 kOhms
Output Impedance	1 kOhm
Current Draw	4 mA
Input	1/4 inch jack
Output	1/4 inch jack
Power Supply	9V DC, 9V battery
Weight	400 g
Connectors	Input jack, Output jack
Dimensions	73mm (W) x 129mm (D) x 59mm (H)
