Boss RC-10R User Manual

Panel Descriptions
3
6 [LEVEL] (LOOP) knob
Adjusts the volume of the phrase loop.
7 [LEVEL] (RHYTHM) knob
Adjusts the volume of the rhythm.
8 RHYTHM indicator
The indicators around the edge light according to the
rhythm playback status.
The center of the indicator shows the division (INTRO,
PTN 1, PTN 2, ENDING) of the rhythm that’s playing.
9 [LOOP] switch
Switches between recording, overdubbing, and
playback.
For an empty phrase
Recording -> Overdubbing -> Playback
For a phrase that contains data
Playback -> Overdubbing
During playback or overdubbing
Hold down the switch for two seconds or longer to
Undo (cancel the recording or the last overdub).
Hold down the switch once again for two seconds or
longer to Redo (cancel the Undo).
While stopped
Hold down the switch for two seconds or longer to clear
the phrase.
10 [RHYTHM] switch
While the rhythm is stopped
Press the switch to play the rhythm.
Hold down the switch for two seconds or longer to turn
SYNC on/o (p. 10).
While the rhythm is playing
Press the switch to add a ll-in.
Hold down the switch for two seconds or longer to
switch the division (PTN 1/PTN 2).
Press the switch twice in succession to stop playback.

Boss RC-10R Specifications

General

Sound effects	Looper, Reverberation
Sound effects quantity	-
DC-in jack	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
6.35 mm (1⁄4-inch) input	1
Display type	LCD
Power source type	DC

Weight and Dimensions

Depth	138 mm
Width	101 mm
Height	63 mm
Weight	620 g
