Boss RC-10R User Manual

2
Panel Descriptions
Top Panel
1
2
5 6
9 10
3
4
7 8
1 Display
Shows the number of the current phrase memory, and
various other information.
2 [VALUE] knob
Selects the parameter that’s shown in the display, or
edits the value.
3 [MENU] button
Accesses various parameters.
MEMO
By pressing the [MENU] button and [EXIT] button simultaneously,
you can save the phrase (p. 17).
4 [EXIT] button
Used to navigate through the menu shown in the
display.
5 LOOP indicator
The indicators around the edge light according to the
status of recording, overdubbing, or playback.
The center of the indicator shows the division (TRK 1,
TRK 2) of the loop that’s playing.

Boss RC-10R Specifications

General

Sound effects	Looper, Reverberation
Sound effects quantity	-
DC-in jack	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
6.35 mm (1⁄4-inch) input	1
Display type	LCD
Power source type	DC

Weight and Dimensions

Depth	138 mm
Width	101 mm
Height	63 mm
Weight	620 g
