Bostitch GF33PT - Loading Fasteners; Loading Finish Nailers; Unloading Finish Nailers; Loading Framing Nailer

-12-
LOADING FASTENERS INTO GBT1850K
1. Depress magazine release button and pull back magazine.
2. Open magazine fully and turn tool sideways with discharge area pointed away from yourself and others.
3. Load brads in channel, point side down, touching bottom.
4. Push magazine forward until latch is engaged.
Magazine Release
Button
Magazine
Pull out
Press
LOADING FASTENERS
N
ever touch trigger or depress contact arm when loading nails. Keep nailer pointing
downward
LOADING FASTENERS INTO GF28WW, GF33PT, GFN1564K & GFN1664K
1. Insert stick of nails into back of magazine.
2. Slide nails forward to front of magazine.
3
. Press button on pusher and slide pusher backward, behind nails.
4. Release button to engage pusher behind nails.
Magazine
Pusher
Button
UNLOADING FASTENERS FROM GF28WW, GF33PT, GFN1564K &
GFN1664K
1. Pull the pusher backwards.
2. Slide unlocked pusher forward, past nails.
3. Remove stick of nails by sliding out the back of the magazine.
UNLOADING FASTENERS FROM THE GBT1850K
1. Depress magazine release button and pull back magazine.
2. Open magazine fully and remove brads from channel.
3. Push magazine forward until latch is engaged.
