GF28WW, GF33PT &

GFN1564K, GFN1664K, GBT1850K

CORDLESS GAS NAILERS

CLAVADORAS INALÁMBRICAS A GAS

CLOUEUSES À GAZ SANS FIL

189774REVA 12/09

STANLEY FASTENING SYSTEMS L.P.

OPERATION and MAINTENANCE MANUAL

MANUAL DE OPERACIÓNY DE MANTENIMIENTO

MANUEL D’INSTRUCTIONS ET D’ENTRETIEN

BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD STUDY THIS MANUAL TO

UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS. KEEP THESE

INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE. IF YOU HAVE ANY QUESTIONS,

CONTACT YOUR BOSTITCH REPRESENTATIVE OR DISTRIBUTOR.

ANTES DE OPERAR ESTA HERRAMIENTA, TODOS LOS OPERADORES DEBERÁN ESTUDIAR

ESTE MANUAL PARA PODER COMPRENDER Y SEGUIR LAS ADVERTENCIAS SOBRE

SEGURIDAD Y LAS INSTRUCCIONES. MANTENGA ESTAS INSTRUCCIONES CON LA

HERRAMIENTA PARA FUTURA REFERENCIA, SI TIENE ALGUNA DUDA, COMUNÍQUESE CON

SU REPRESENTANTE DE BOSTITCH O CON SU DISTRIBUIDOR.

LIRE ATTENTIVEMENT LE PRÉSENT MANUEL AVANT D’UTILISER L’APPAREIL. PRÉTER UNE

ATTENTION TOUTE PARTICULIÈRE AUX CONSIGNES DE SÉCURITÉ ET AUX

AVERTISSEMENTS. GARDER CE MANUEL AVEC L’OUTIL POUR FUTUR RÉFÉRENCE. SI

VOUS AVEZ DES QUESTIONS, CONTACTEZ VOTRE REPRÉSENTANT OU VOTRE

CONCESSIONNAIRE BOSTITCH.

Table of Contents

Other manuals for Bostitch GFN1664K

Original Instructions236 pages

Questions and Answers:

E
eric20Aug 8, 2025
Why is my Bostitch GFN1664K Nail Gun skipping nails?
- J
  Janet LewisAug 8, 2025
  If your Bostitch Nail Gun is skipping nails or has an intermittent feed, ensure you are using only recommended nails. Try cleaning and lubricating the tool. If the ribbon spring is weakened or damaged, replace it. Also, a worn or damaged pusher should be replaced. Make sure to pull the trigger all the way. If the temperature is too low, warm up the fuel cell under 120°F (50°C). Other solutions may include replacing the piston ring, piston, or cylinder piston ring. For further assistance, contact Bostitch for a replacement.
D
Daniel ThompsonAug 14, 2025
What to do if my Bostitch GFN1664K Nail Gun doesn't drive nails but the green light is on?
- K
  Karen SanchezAug 14, 2025
  If the fan is working and the light indicator shows green on your Bostitch Nail Gun, but it's not driving nails or the operation is unstable, ensure you push the contact arm all the way. If the temperature is too low, warm up the fuel cell to under 120°F (50°C). Check the fuel cell and exchange it with a new one if it's insufficient. Inspect the filter and clean it as instructed on the maintenance sheet. For spark plug wire, spark plug issues, contact Bostitch for replacement.
J
Jose SpencerAug 20, 2025
How to fix nail jams and bent nails in my Bostitch GFN1664K?
- M
  Michelle GreenAug 20, 2025
  If your Bostitch Nail Gun is experiencing nail jams and bent nails, make sure you are using only recommended nails. If the pusher is worn or damaged, replace it. For a worn driver blade, contact Bostitch for replacement.
T
Troy KnightAug 27, 2025
What to do if my Bostitch GFN1664K Nail Gun operates but doesn't drive nails?
- E
  Emily RussoAug 27, 2025
  If your Bostitch Nail Gun operates but doesn't drive any nails, start by clearing any jams. Then, clean and lubricate the nailer. If the ribbon spring is weakened or damaged, replace it. Ensure you are using only recommended nails. You can also try pushing the driver blade with a slotted-head screwdriver and putting the piston back to the highest position.
K
Kristine GuzmanSep 1, 2025
Why doesn't the fan operate when I press the lever on my Bostitch GFN1664K?
- M
  maureen10Sep 1, 2025
  If the fan on your Bostitch Nail Gun does not operate when the push lever is pressed, first check if the magazine is empty and load more nails if needed. If the light indicator is red, charge the battery. If the light is green, contact Bostitch for replacement.

Bostitch GFN1664K Specifications

General

Brand	Bostitch
Model	GFN1664K
Category	Nail Gun
Language	English

Summary

Tool Illustration and Specifications

Tool Illustration

Visual breakdown of components for finish and framing nailer models.

Tool and Charger Specifications

Technical details for various Bostitch nailer models and their chargers.

Introduction and Warranty Information

Product Introduction

General overview of Bostitch cordless gas nailers and manual purpose.

Limited Warranty

Terms and conditions for the Bostitch product warranty.

Safety Instructions and Warnings

General Safety and Tool Warnings

Essential safety precautions, eye protection, tool/fuel hazards.

Battery and Charger Safety

Critical safety for batteries, chargers, and maintenance.

Battery Charger Precautions

Specific precautions for charger use, including in-car.

Tool Operation and Maintenance

Tool Battery Usage

Instructions for using and charging the tool battery.

Fuel Cell Preparation and Installation

Steps to prepare and install the fuel cell.

Tool Operation Safety and Testing

Safety guidelines and tests for proper tool operation.

Loading and Jam Clearing

Procedures for loading fasteners and clearing jams.

Depth Adjustment and Accessories

Adjusting fastener depth and installing accessories.
