GF28WW, GF33PT &
GFN1564K, GFN1664K, GBT1850K
CORDLESS GAS NAILERS
CLAVADORAS INALÁMBRICAS A GAS
CLOUEUSES À GAZ SANS FIL
189774REVA 12/09
STANLEY FASTENING SYSTEMS L.P.
OPERATION and MAINTENANCE MANUAL
MANUAL DE OPERACIÓNY DE MANTENIMIENTO
MANUEL D’INSTRUCTIONS ET D’ENTRETIEN
BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD STUDY THIS MANUAL TO
UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS. KEEP THESE
INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE. IF YOU HAVE ANY QUESTIONS,
CONTACT YOUR BOSTITCH REPRESENTATIVE OR DISTRIBUTOR.
ANTES DE OPERAR ESTA HERRAMIENTA, TODOS LOS OPERADORES DEBERÁN ESTUDIAR
ESTE MANUAL PARA PODER COMPRENDER Y SEGUIR LAS ADVERTENCIAS SOBRE
SEGURIDAD Y LAS INSTRUCCIONES. MANTENGA ESTAS INSTRUCCIONES CON LA
HERRAMIENTA PARA FUTURA REFERENCIA, SI TIENE ALGUNA DUDA, COMUNÍQUESE CON
SU REPRESENTANTE DE BOSTITCH O CON SU DISTRIBUIDOR.
LIRE ATTENTIVEMENT LE PRÉSENT MANUEL AVANT D’UTILISER L’APPAREIL. PRÉTER UNE
ATTENTION TOUTE PARTICULIÈRE AUX CONSIGNES DE SÉCURITÉ ET AUX
AVERTISSEMENTS. GARDER CE MANUEL AVEC L’OUTIL POUR FUTUR RÉFÉRENCE. SI
VOUS AVEZ DES QUESTIONS, CONTACTEZ VOTRE REPRÉSENTANT OU VOTRE
CONCESSIONNAIRE BOSTITCH.

Table of Contents

Other manuals for Bostitch GFN1564K

Preview: Original Instructions
Original Instructions236 pages

Questions and Answers

  • A
    Adam MillerAug 11, 2025
    Why is my Bostitch GFN1564K Nail Gun skipping nails?
    • A
      Andrew KingAug 11, 2025
      If your Bostitch Nail Gun is skipping nails or has an intermittent feed, ensure you are using only recommended nails. Try cleaning and lubricating the tool. If the ribbon spring is weakened or damaged, replace it. Also, a worn or damaged pusher should be replaced. Make sure to pull the trigger all the way. If the temperature is too low, warm up the fuel cell under 120°F (50°C). Other solutions may include replacing the piston ring, piston, or cylinder piston ring. For further assistance, contact Bostitch for a replacement.
  • B
    brettgarciaAug 18, 2025
    What to do if my Bostitch Nail Gun doesn't drive nails but the green light is on?
    • K
      krobbinsAug 18, 2025
      If the fan is working and the light indicator shows green on your Bostitch Nail Gun, but it's not driving nails or the operation is unstable, ensure you push the contact arm all the way. If the temperature is too low, warm up the fuel cell to under 120°F (50°C). Check the fuel cell and exchange it with a new one if it's insufficient. Inspect the filter and clean it as instructed on the maintenance sheet. For spark plug wire, spark plug issues, contact Bostitch for replacement.
  • J
    Justin BellAug 23, 2025
    How to fix nail jams and bent nails in my Bostitch GFN1564K?
    • J
      Joanna MartinAug 23, 2025
      If your Bostitch Nail Gun is experiencing nail jams and bent nails, make sure you are using only recommended nails. If the pusher is worn or damaged, replace it. For a worn driver blade, contact Bostitch for replacement.
  • J
    Jessica ArmstrongAug 30, 2025
    What to do if my Bostitch GFN1564K operates but doesn't drive nails?
    • M
      Mr. Jason BeasleyAug 30, 2025
      If your Bostitch Nail Gun operates but doesn't drive any nails, start by clearing any jams. Then, clean and lubricate the nailer. If the ribbon spring is weakened or damaged, replace it. Ensure you are using only recommended nails. You can also try pushing the driver blade with a slotted-head screwdriver and putting the piston back to the highest position.
  • C
    Christian ChungSep 4, 2025
    Why doesn't the fan operate when I press the lever on my Bostitch GFN1564K?
    • D
      David HeathSep 4, 2025
      If the fan on your Bostitch Nail Gun does not operate when the push lever is pressed, first check if the magazine is empty and load more nails if needed. If the light indicator is red, charge the battery. If the light is green, contact Bostitch for replacement.

Bostitch GFN1564K Specifications

General IconGeneral
Operating Pressure70-120 PSI
Depth AdjustmentYes
Jam ClearingTool-free
No-Mar TipYes
Warranty7 years
Fastener Length1-1/4 - 2-1/2 in
Magazine Capacity100
Power SourcePneumatic
Firing ModeSequential or Contact
