Trigger valve housing leaks air O-ring cut or cracked . . . . . . . . . . . . . .Replace O-ring
Trigger valve stem leaks air O-ring/seals cut or cracked . . . . . . . . .Replace trigger valve assembly
Frame/nose leaks air Loose nose screws . . . . . . . . . . . . . . .Tighten and recheck
O-ring or Gasket is cut or cracked . . . .Replace O-ring or gasket
Bumper cracked/worn . . . . . . . . . . . . .Replace bumper
Frame/cap leaks air Damaged gasket or seal . . . . . . . . . . .Replace gasket or seal
Cracked/worn head valve bumper . . . .Replace bumper
Loose cap screws . . . . . . . . . . . . . . . .Tighten and recheck
Failure to cycle Air supply restriction . . . . . . . . . . . . . . .Check air supply equipment
Tool dry, lack of lubrication . . . . . . . . . .Use BOSTITCH Air Tool Lubricant
Worn head valve O-rings . . . . . . . . . . .Replace O-rings
Broken cylinder cap spring . . . . . . . . . .Replace cylinder cap spring
Head valve stuck in cap . . . . . . . . . . . .Disassemble/Check/Lubricate
Lack of power; slow to cycle Tool dry, lacks lubrication . . . . . . . . . . .Use BOSTITCH Air Tool Lubricant
Broken cylinder cap spring . . . . . . . . . .Replace cap spring
O-rings/seals cut or cracked . . . . . . . . .Replace O-rings/seals
Exhaust blocked . . . . . . . . . . . . . . . . .Check bumper, head valve spring, muffler
Trigger assembly worn/leaks . . . . . . . .Replace trigger assembly
Dirt/tar build up on driver . . . . . . . . . . .Disassemble nose/driver to clean
Cylinder sleeve not seated correctly
on bottom bumper . . . . . . . . . . . . . . . .Disassemble to correct
Head valve dry . . . . . . . . . . . . . . . . . . .Disassemble/lubricate
Air pressure too low . . . . . . . . . . . . . . .Check air supply equipment
Skipping fasteners; intermittent feed Worn bumper . . . . . . . . . . . . . . . . . . . .Replace bumper
Tar/dirt in driver channel . . . . . . . . . . . .Disassemble and clean nose and driver
Air restriction/inadequate air flow through
quick disconnect socket and plug . . . . .Replace quick disconnect fittings
Worn piston O-ring . . . . . . . . . . . . . . . .Replace O-ring, check driver
Tool dry, lacks lubrication . . . . . . . . . . .Use BOSTITCH Air Tool Lubricant
Low air pressure . . . . . . . . . . . . . . . . .Check air supply system to tool
Loose magazine nose screws . . . . . . .Tighten all screws
Fasteners too short for tool . . . . . . . . .Use only recommended fasteners
Bent fasteners . . . . . . . . . . . . . . . . . . .Discontinue using these fasteners
Wrong size fasteners . . . . . . . . . . . . . .Use only recommended fasteners
Leaking head cap gasket . . . . . . . . . . .Tighten screws/replace gasket
Trigger valve O-ring cut/worn . . . . . . . .Replace O-ring
Broken/chipped driver . . . . . . . . . . . . .Replace driver (check piston O-ring)
Dry/dirty magazine . . . . . . . . . . . . . . . .Clean/lubricate use BOSTITCH
Air Tool Lubricant
Worn magazine . . . . . . . . . . . . . . . . . .Replace magazine
Fasteners jam in tool Driver channel worn . . . . . . . . . . . . . . .Replace nose/check door
Wrong size fasteners . . . . . . . . . . . . . .Use only recommended fasteners
Bent fasteners . . . . . . . . . . . . . . . . . . .Discontinue using these fasteners
Loose magazine/nose screws . . . . . . .Tighten all screws
Broken/chipped driver . . . . . . . . . . . . .Replace driver
TROUBLE SHOOTING
Skipping fasteners; intermittent feed Feed piston dry . . . . . . . . . . . . . . . . . .Add BOSTITCH Air Tool Lubricant
in hole in feed piston cover
Feed piston O-rings cracked/worn . . . .Replace O-rings/check bumper and spring.
Lubricate assembly.
Check Pawl binding . . . . . . . . . . . . . . .Inspect Pawl and spring on door.
Must work freely.
Canister post not set correctly . . . . . . .Set canister post for length of nails
being used
Broken weld wires in nail coil . . . . . . . .Remove coil of nails and use another coil
Fasteners jam in tool/canister Wrong size fasteners for tool . . . . . . . .Use only recommended fasteners/check
canister bottom adjustment
Broken welded wires in nail coil . . . . . .Remove coil of nails and use another coil
PROBLEM CAUSE CORRECTION
11
COIL NAILERS
