BougeRV PWM NEGATIVE GROUND - P2410 N Controller Dimensions

Controller Dimension
3.53inch (89.7mm)
1.36inch (34.7mm)
4.41inch (112mm)
4.72inch(120mm)
1.27inch (32.5mm)
0.07inch (2mm)
•Product Dimension: 4.72*3.53*1.27 inch (120*89.7*32.5mm)
•Installation Area Dimension: 4.41*1.36 inch (112*34.7mm)
•Drill Hole Size : 0.12*0.07 inch (3.2*2mm)
φ
0.12inch (3.2mm )
•Installation Hole size : 0.19*0.29 inch (5*7.5mm)
P2410N
15
