6 Dismantling
MN031-447-S0-20101217-EN NightKNIFE / Ligator 29
1
3. Ensure that the blade with insertion aid E is aligned to
the middle of the fixed jaw A1 at position 1.
4. If necessary, use your fingers to align insertion aid E1 in
the middle.
5. Hold the insertion aid E1 by the sides in position 1 and
move the sliding tube slowly in the arrow direction until
the blade E2 distinctly clicks in place.
ª
With the blade attached, the spring remains
compressed.
