6 Dismantling
30 NightKNIFE / Ligator MN031-447-S0-20101217-EN
6. Using the wedge on the insertion aid E1, release the
blade E2 from the latch.
ª
The spring relaxes and the sliding tube snaps back.
7. Pull out the insertion aid and blade E in the arrow
direction and dispose of the blade and insertion aid E.
Reconditioning the blade and insertion aid is prohibited.
Pos: 12 /679-BOWA/HF-I nstrumente/Ligator "NightKNIFE"/07. Aufbereitung @ 5\mod_1277 986531480_6.doc @ 40765 @ 12222223322222
MN031-447-S1 EN
