BÖWE P15 - Floor Load; Dimensions

28
P12-P15-P18
5 Installation 5
5.3 Floor Load
The place of installation must be designed to comply with the specified floor load. This consists of:
Static load = machine weight + max. solvent filling
Dynamic load = cage centrifugal force with normally distributed, spin-damp garments
Do not forget to take into account the centrifugal forces that arise during the spin processes, according to
the local conditions (ground, supporting walls, etc.). No resonance is permitted.
Please consult building specialists.
5.3.1 Dimensions
Slimline
Crossline
P12
P15
P18
P12
P15
P18
Depth*
mm
inches
1200
47.2
1310
51.6
1420
55.9
1200
47.2
1310
51.6
1420
55.9
Width*
mm
inches
1080
42.5
1080
42.5
1080
42.5
1080
42.5
1080
42.5
1080
42.5
Portion of the floor surface for
force transmission
m
2
ft
2
1.3
14.0
1.41
15.2
1.53
16.4
1.3
14.0
1.41
15.2
1.53
16.4
Weight without solvent
kg
lb
1140
2513
1240
2734
1340
2954
1240
2734
1340
2954
1440
3175
Weight with solvent (stat. load)
kg
lb
1590
3505
1770
3902
1950
4299
1690
3726
1870
4123
2050
4520
Cage centrifugal force (dyn.
load)
N
lbs
5900 **
1326 **
7300 **
1640 **
8800 **
1977 **
5900 **
1326 **
7300 **
1640 **
8800 **
1977 **
Floor load (stat. + dyn. load)
N/m
2
lbs/ft
2
16500 **
344 **
17500 **
365 **
18300 **
382 **
17300 **
361 **
18200 **
380 **
18900 **
394 **
* Portion of the machine dimensions that is decisive for the size of the cage centrifugal force and floor
load.
** Calculated with:
- 12 kg-15 kg-18 kg (26.5/33.1 /39.7 lb) loaded weight, with 50% of this unevenly distributed
- Mixed outer clothing
- EBS
- 500 rpm
Building specialists will find the best solution, from both a structural and economic point of view, for the
design of the foundation. They take into consideration the system or machine-related conditions and the
local particulars.
Use a load dispatcher frame if the permissible load for your floor is not sufficient.
