BÖWE P15 - Electrical Connection

44
P12-P15-P18
7 Connection 7
7.3 Electrical Connection
7.3
Caution
Only trained electricians are permitted to work on the electrical system.
Note the supply voltage (on the nameplate). Connect L1 /L2 /L3, neutral and ground wires with the
appropriate cross section and fusing. Pass the cable into the switch panel through the PVC screwed
union provided and connect to terminal.
Main switch connection
The main switch must be connected at the customer with an approved cable. Strip the cable right before
the main switch only. Do not lay stripped cable in the cable trunking.
Ground-fault circuit interrupter at the customer
Ground-fault circuit interrupter at the customer
In case of a fault current breaker integrated in the building it is recommandable
to make sure, if it is applicable to the machine with variable speed drive.
P12 /P15 /P18
Operating
load
kW
Max. Current
A
Fuse
A
400 V, 50 Hz
Steam with distillation
7.4
18
25
Electric with distillation
20.1
38
50
Steam with distillation with Slimsorba
8.1
20
25
Electric with distillation with Slimsorba
26.5
49
63
P12 /P15 /P18
Operating
load
kW
Max. current
A
Fuse
A
230 V, 60 Hz
Steam with distillation
7.4
26
35
Electric with distillation
20.1
60
63
Steam with distillation with Slimsorba
8.1
30
35
Electric with distillation with Slimsorba
26.5
79
80
