BÖWE P15 - Page 46

39
P12-P15-P18

7 Connection 7
Crossline
707770-20-0
We reserve the right to change dimensions!
Item
Medium
NW
mm
Inch
-X-
mm
-X-
in.
-Y-
mm
-Y-
in.
1
Steam heater battery machine
15
1/2
854
33.6
1495
58.8
2
Steam distillation
15
1/2
60
2.3
1540
60.6
3
Condensate heater battery machine
15
1/2
979
38.5
1430
56.2
4
Condensate distillation
15
1/2
62
2.4
405
15.9
5
Cooling water inlet
20
3/4
1650
64.9
2035
80.1
6
Cooling water outlet, distillation
20
3/4
617
24.2
1900
74.8
7
Cooling water outlet, refrigeration
unit
20
3/4
1700
66.9
2030
79.9
8
Compressed air
8
1/4
793
31.2
1615
63.5
9
Electric connection (front side top)
-
-
845
33.2
1985
78.1
11
Still rake out system – pump out
-
-
74
2.9
1350
53.1
-There must be a measuring potentiometer installed (on the machine) between the machine and
customer wiring system.
