4 Transport 4
In order to guarantee that no damages result from the handling, we recommend that you
consult with the appropriate experts for correct transport, installation and connection.
You must provide suitable tools and equipment for unloading, transporting, machine entry
and installation. For example: crane, forklift, elevating truck, pulley block, rope, winch,
crowbar, rollers, wooden block, wedges.
Caution
Attention: Note the center of gravity of the machine and secure
against lateral tipping.
4.1 Entry 4.1
Normally the machine and distillation unit are packed in a crate or shipping box and kept in an upright
position when being transported and brought in.
Package dimensions (box measurements) P25/P30
Machine Distillation
Width mm (in) 1510 (59.4) 1200 (47.2)
Depth mm (in) 2380 (93.7) 2350 (92.5)
Height mm (in) 2450 (96.5) 2450 (96.5)
Normal dimensions after unpacking (entry dimensions)
Width mm (in) 1440 (56.7) 1040 (40.9)
Depth mm (in) 2260 (89.0) 2260 (89.0)
Height mm (in) 2350 (92.5) 2350 (92.5)
Entry dimensions (without fan, flap housing, lint filter suspension device and various
cooling water pipes)
Height mm (in) 2145 (84.4) 2200 (86.6)
Entry dimensions (without fan, angle bracket, flap housing and lint filter suspension
device)
Width mm (in) 1260 (49.6)
Height mm (in) 2145 (84.4)
Removing machine from the pallet:
Must be done by transport experts.
Lift the machine only at sturdy points.
Note the center of gravity of the machine and secure against lateral tipping.
P25/P30
