6 Fixing the Machine in Place 6
Adhesive plugs/shear connectors
Steps:
Position the machine in its intended position.
Use the holes of the angle bracket as a drilling template.
Prebore with 16 mm (.6 in) stone drill. Drill in vertically!
Remove the machine or angle bracket.
Boreholes:
Drill the diameter and depth according to the information
provided by the plug manufacturer and blow out any dust.
For further steps, refer to the information provided by the plug manufacturer.
Note the hardening time.
Position the machine or attach the angle bracket and level.
If the floor is uneven, level the machine with wedges and even out the surface with filler (epoxy
resins).
Tighten the nuts evenly.
P25/P30
