Bowflex HVT - Page 130

130
19. Using a 6mm hex wrench, attach the new Right Platform Frame to
the Frame Assembly. Insert the hardware that attaches the Front Platform
Framerst.
Note: Do not pinch the routing wire when attaching the Right Platform
Frame.
20. Tie the Routing Wire to the end of the Right Lower Rope. Be sure
to secure it well since the rope will begin to be under tension when fully
routed through the Right Platform Frame.
21. Place the Securing Ball near the Right Support Arm so you can easily
grab and install it onto the Right Lower Rope.
22. Using the routing wire, slowly pull the Lower Right Rope through the
Right Platform Frame and attach the Securing Ball.
23. Safely release the Lower Rope.
