16
1. Unplug the AC Adapter from the wall outlet and machine.
2. Using a #2 Phillips screwdriver, remove the 4 indicated screws from the
Lower Pulley Shrouds.
3. Remove the Lower Pulley Shrouds noting how the Ropes route through
them.
4. Using a 6mm hex wrench, loosen the 6 indicated screws that secure
the Support Arms to the Platform Base.
5. Place a sheet of paper or thin cardboard as shown beside Platform
Decking #2 to protect the paint.
6. Using a standard screwdriver, insert the end of it and pry Platform
Decking #2 out of the Platform Frame.
Platform Decking #1
Platform Decking #2
Lower Pulley
Shrouds
Support Arms
To Next Page
