64
1. Unplug the AC Adapter from the wall outlet and machine.
2. Using a #2 Phillips screwdriver, remove the 5 indicated screws (by
ovals) from each of the Rear Middle Pulley Shrouds and place them
outside the work area.
3. Using a #2 Phillips screwdriver, remove the two indicated screws (by
arrows) from the Upper Rear Shroud.
4. Remove the Upper Rear Shroud and place out of the work area.
5. Fully push the Floating Pulleys toward the rear of the machine.
Rear Middle Pulley
Shroud
Floating Pulleys
Upper Rear
Shroud
To Next Page
