24
1. Unplug the power cord from the machine and wait 5 minutes.
2. Using two 6mm hex wrenches, remove the indicated hardware from the Wheel Bracket that attaches the Roller Wheel Assembly.
In order to avoid possible serious injury when removing the hardware from the Roller Wheel Assemblies, be careful to avoid ngers
or hands being caught or pinched. Also be aware that the Legs and the Upper Handlebars are connected and when either of these
parts move the other does as well.
Roller Wheel
Assembly
3. If there was a Large Washer between the Roller Wheel and the Wheel
Bracket, discard them. They are NOT reused.
4. Install the Felt Washers on the Axle between the Roller Wheel As-
sembly and the Wheel Bracket.
The Wheel Bracket is designed so the Axle can only be inserted from
one side.
Axle
Felt Washer
Wheel
Bracket
Wheel
Bracket
Felt Washer
5. Re-attach the hardware and fully tighten using two 6mm hex wrenches.
6. Final Inspection
Inspect your machine to ensure that all hardware is tight and components are properly assembled.
Do not use until the machine has been fully assembled and inspected for correct performance in accordance with the Owner’s
Manual.
Felt Washer
