Replace the Frame Assembly on the

Bowﬂex Max Trainer

M3 / M5

Skill Level: III

8016597.081517.A

Replacement Procedure

NOTICE: This document provides instructions for the replacement of the Frame Assembly on the Bowﬂex Max Trainer

M3 / M5.

If you need assistance, please call Bowﬂex Customer Service at 1-800-605-3369.

This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Read and understand

all Warnings on this machine.

Tools Required (inlcuded)

5mm hex wrench

#2 Phillips screwdriver 6mm hex wrench 13mm wrench

8mm hex wrench

Nautilus, Inc., (800) NAUTILUS / (800) 628-8458, www.NautilusInc.com - Customer Service: North America (800) 605-3369, csnls@nautilus.com | outside U.S. www.nautilusinternational.com | Printed in China | © 2017 Nautilus,

Inc. | ® indicates trademarks registered in the United States. These marks may be registered in other nations or otherwise protected by common law. Bowﬂex, the B logo, and Bowﬂex Max Trainer are trademarks owned by or

licensed to Nautilus, Inc.

Important Safety Instructions - Before servicing or using this equipment, obey the following warnings:

This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Read and understand all

Warnings on this machine.

• Read and understand the Part Replacement Procedure before working on the machine. Failure to obey the instructions and safety warnings could cause

injury to the service technician or bystanders.

• Keep bystanders and children away from the product being serviced at all times.

•Makesurethattherepairisdoneinanappropriateworkspaceawayfromfoottrafcandexposuretobystanders.

• Disconnect all power and allow to sit for 5 minutes before you service this machine.

• Some components of the equipment can be heavy or awkward. Enlist the service of a second person when you do maintenance steps involving these

components. Do not try to do heavy or awkward steps on your own.

• If replacement parts are necessary, use only genuine Nautilus replacement parts and hardware. Failure to use genuine replacement parts can cause a

risk to users, keep the machine from operating correctly and will void the warranty.

• Be sure that all warning stickers and instructional placards applied to the product stay present and in good condition when doing maintenance or replac-

ing components. If necessary request replacement warning stickers or placards from Nautilus customer service.

• Do not try to change the design or functionality of the machine being serviced as this can adversely effect user safety and will void the warranty.

•Donotusethemachineuntilallshrouds,instructions,warninglabelsandcorrectfunctionalityhavebeenveriedandtestedforcorrectperformance.

A B C D E F

G H

I J K L M N O

Item Qty Description Item Qty Description

A 8 Socket Head Hex Screw, M6x1.0x8 H 10 Socket Head Hex Screw, M6x1.0x20

B 4 Socket Head Hex Screw, M8x1.25x55 I 4 Socket Head Hex Screw, M10x1.5x25

C 12 Washer, Flat M8x18 J 4 Washer, Flat M10x23

D 6 Socket Head Hex Screw, M8x1.25x20 K 2 Washer, Flat M8x24

E 1 Pan Phillips Screw, M5x0.8x20 L 4 Washer, Flat M6x13

F 2 Cap M 10 Lock Washer, M6

G 4 Lock Nut, M8 N 6 Lock Washer, M8

Hardware
