55
9. Re-install all remaining parts that were
removed in reverse order.
When re-installing the Rear Shroud to the
Frame Assembly, place the upper part of the
Rear Shroud onto the Frame Assembly. Then
pivot it downward into place. There are 6
tabs that will secure it.
8. Remove the old Decorative Shroud. To attach
the new Decorative Shroud, reverse the order of
removal.
10. Final Inspection
Inspect your machine to ensure that all hardware is tight and components are properly assembled.
Do not use until the machine has been fully assembled and inspected for correct performance in
accordance with the Owner’s Manual.
