Bowflex Max Trainer SE - Replace the Main Mast Cable

56
Replace the Main Mast Cable on
the BowFlex
™
Max Trainer
™
SE/SEi machines
Replacement Procedure
NOTICE: This document provides instructions for the replacement of the Main Mast (or Console) Cable on the Bow-
Flex™ Max Trainer™ SE/SEi exercise machines.
If you need assistance, please call BowFlex Customer Service (if purchased in US/Canada) or your local distributor (if
purchased outside US/Canada). To find your local distributor, go to: global.bowflex.com
Skill Level: II
Estimated Procedure Time: 30-45
minutes
8031187.101523.A
BowFlex Inc., www.bowflex.com, 5415 Centerpoint Parkway, Groveport, OH 43125 U.S.A. - Customer Service: North America (800) 605-3369, cs@bowflex.com | out-
side U.S. global.bowflex.com | Printed in China | © 2023 BowFlex Inc. | BowFlex and the BowFlex logo are trademarks owned or licensed by BowFlex Inc., registered or
otherwise protected by common law in the United States and other nations. |
ORIGINAL DOCUMENT - ENGLISH VERSION ONLY
This icon means a potentially hazardous situation which, if not avoided, could result in death or
serious injury. Read and understand all Warnings on this machine.
Tools Required (not included)
Short #2 Phillips screwdriver Standard screwdriver
14mm open faced wrench
(3) Zip-Ties (Replacements)
Something to cut a Zip-Tie
Important Safety Instructions - Before servicing or using this equipment, obey the following warnings:
This icon means a potentially hazardous situation which, if not avoided, could result in death or serious
injury. Read and understand all Warnings on this machine.
• Read and understand the Part Replacement Procedure before working on the machine. Failure to obey the
instructions and safety warnings could cause injury to the service technician or bystanders.
• Keep bystanders and children away from the product being serviced at all times.
• Disconnect all power to the machine before you service it.
• Make sure that the repair is done in an appropriate work space away from foot traic and exposure to
bystanders.
• Disconnect all power and allow to sit for 5 minutes before you service this machine.
• Some components of the equipment can be heavy or awkward. Enlist the service of a second person when you do
maintenance steps involving these components. Do not try to do heavy or awkward steps on your own.
• Use only replacement parts and hardware that are supplied or approved by BowFlex. Failure to use BowFlex-
approved replacement parts can adversely aect the safety and functionality of the equipment creating a risk to
users and will void the warranty.
• Be sure that all warning stickers and instructional placards applied to the product stay present and in good con-
dition when doing maintenance or replacing components. If at any time the Warning labels become loose, unread-
able or dislodged, replace the labels. If purchased in US/Canada, contact Customer Service for replacement labels.
If purchased outside US/Canada, contact your local distributor for them.
• Do not try to change the design or functionality of the machine being serviced as this can adversely affect user
safety.
• Do not use the machine until all shrouds, instructions, warning labels and correct functionality have been verified
and tested for correct performance.
•
SAVE THESE INSTRUCTIONS
