3. Move Lock Pin Actuators
NOTICE: Remove the Lock Pin Actuators and re-install in the inner set of screw holes in the Base End Shrouds to t the
120-lb barbell conguration.
#2
X4
Lock pin
actuator
(X2)
Inner
Outer
#2
X4
Lock pin
actuator
(X2)
4. Put Upgrade Weight Plates, Original Weight Plates and Barbell Assembly in the Base
In order to avoid possible serious injury, when placing the Weight Plates in the Base Assembly, be careful
to avoid ngers or hands being caught or pinched.
Note: Be sure that the Weight Plates are fully seated in the Base. Ensure there are no large gaps between Weight
Plates, and all weight plate tabs are aligned and locked together. Make sure the locking tab at the top of each
Base End Shroud is seated in the selection lip at the top of the back Weight Plate.
Locking tab
Upgrade
plates (4)
Upgrade
plates (4)
