Replacing Parts
Walking Belt Replacement
Troubleshooting Symptom: Cracked rubber on walking belt.
User feels static electricity or small shocks while running or
walking.
Disconnect all power and allow to sit for 5 min. before you
service this machine
Note: Set the hardware safely aside as you disassemble
components. Identify the correct size hardware for
each step to assemble the machine again.
1. Remove the motor cover (Figure 1).
2. Remove the plastic side step cover (Figure 2).
Figure 1
Figure 2
Service Manual
13
