Bowflex Series 3 - Page 19

Replacing Parts
15. Carefully remove the 4 plastic spacers between
the deck and frame mounts (Figure 9). Set aside for
reinstallation.
16. Lift and tilt the deck with belt from the frame, and
remove the old belt. (See Figure 10.)
17. Clean deck with damp rag. Clean and remove any
debris from below the deck.
Figure 9
Figure 10
Walking Belt Replacement (cont.)
Service Manual
17
