Assembly / Owner’s Manual
10
Hardware / Tools / Assembly
Item Qty Description Item Qty Description
A 22 Socket Hex Head Screw, M8x1.25x20 Black E 6 Curved Washer, M8x18 Black
B 4 Socket Hex Head Screw, M8x1.25x70 Black F 4 Pan Phillips Head Screw, M3.9x16 Black
C 26 Lock Washer, M8x18 Black G 2 Pan Phillips Head Screw, M5x10 Black
D 20 Flat Washer, M8x18 Black
Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be remaining Hardware
after the proper assembly of your machine.
6mm #2
Tools
Included
DO NOT CUT the Shipping Strap on the Base Assembly until it has been placed face up as shown in the
appropriate work space.
*
A
B
C
D
E
F G
To Next Page
