Bowflex Treadmill 7 - Treadmill Assembly and Components; Parts Identification

Assembly / Owner’s Manual
9
Item Qty Description Item Qty Description
1 1 Console Assembly 11 1 Crossbar
2 1 Upper Junction Cover, Left 12 1 Upright, Right
3 1 Handlebar Assembly, Left 13 1 Base Shroud, Right
4 1 Junction Cover End Cap, Left 14 1 Base Assembly
5 1 Lower Junction Cover, Left 15 1 Upright, Left
6 1 Handlebar Assembly, Right 16 1 Base Shroud, Left
7 1 Junction Cover End Cap, Right 17 1 Power Cord
8 1 Lower Junction Cover, Right 18 1 Safety Key
9 1 Upper Junction Cover, Right 19 1 Document Kit / Hardware Card
10 1 Tray 20 1 Heart Rate Armband
DO NOT CUT the Shipping Strap ( * ) or Shipping Zip-Tie ( ** ) on the Treadle Assembly until instructed.
When moving the Deck Assembly, be sure to grasp the sides of it. Do not grasp the Walking Deck Release
Button. Pressing the Walking Deck Release Button releases the locking mechanism on the hydraulic lift.
Parts
1
18
9
5
2
3
8
10
14
11
13
12
17
16
15
6
19
20
7
4
