BPC PowerGem Plus RT 6 kVA - Default Chapter; Table of Contents

- 1 -
CONTENTS PAGE No
CHAPTER 1 Safety 1
1.1 Safety notes 1
1.2
Symbols used in this guide
1
CHAPTER 2 Main Features 2
2.1
Summarization
3
2.2
Functions and Features
3
CHAPTER 3
Installation
3
3.1
Unpack checking
3
3.2
UPS Module Outlook
4
3.3
LCD control panel
6
3.4
Installation notes
7
3.5
External Protective Devices
9
3.6
Power Cables
10
3.7
Power cable connect
10
3.8 Battery connection 10
3.9
UPS Multi－Module Installation
10
CHAPTER 4 Operation
11
4.1 Operation Modes
13
4.2 Turn on/off UPS
19
4.3 LCD Display instruction
21
4.4 Parameters setting
22
APPENDIX 1
Specifications
24
APPENDIX 2
Communication port definition
24
APPENDIX 3
Option
25
APPENDIX 4
UPS message table
26
Important safety instructions – Save these instructions
Dangerous voltages and high temperature exist within the UPS System. During the
installation, operation and maintenance, please abide by the local safety instructions and
relative laws, otherwise it may result in personnel injury or damage to the equipment.
Safety instructions in this manual act as a supplementary for the local safety instructions.
Our company will not assume the liability caused by not following any local safety
instructions.
