Output
Output type Single phase + Ground
Output precision ±1.0%；
Voltage distortion（THD）
≤2% at 100% liner load
≤5% at 100% non-liner load
Rating voltage 208/220/230V/240Vac
Frequency precision ±0.1%
Rating Frequency 50Hz/60Hz
Freqency track speed 1Hz/s
Overload
105%~110%，10min
110%~130% 1min
≥130% 200ms
Peak value factor 3:1
Efficiency at normal ≥93%
Dynamic respond
5.0%
20ms
DC heft ≤500mV
Switch
Time
Between Normal mode
0ms
Between inverter and
bypass
0ms
unlock：＜15ms (50Hz), ＜13.33ms (60Hz)
Noise <55dB（1m）
Display LCD+LED
Safety Meeting IEC62040-1 GB4943。
Max input voltage 320Vac，1Hr
EMI
Conduction ：IEC 62040-2
Radiation ：IEC 62040-2
Harmonics ：IEC 62040-2
EMS IEC 62040-2
MTBF 250,000Hr 1＋1 400,000Hr
MTTR 30min
Isolation resistance > 2MΩ（500Vdc）
Isolation intension 2820Vdc， <3.5mA，1min
Surge Meeting IEC60664-1 1.2/50uS+8/20uS 6kV/3kA.
Protection IP20
Parallel circumfluence 1＋1≤8%，N＋1≤3%
Parallel equal current
1＋1≤8%，N＋1≤10%
