bq Hephestos 2 - Print Bed Clamp System

Levelling Guide
8
Print bed clamp system
If the bed is not sitting flat on the Y-axis, putting pressure on the tabs to hold it in place could cause
the bed to warp slightly and cause issues in the center area of the bed.
A solution to this problem is to print this part as an alternative. It holds the bed in place without
pressure from the top, using the same holes as the original system.
The bracket holds the side wings
of the print bed and fits in the
holes of the original system
Original clamp system
Alternative system
