Braeburn 1020NC User Manual

8
Detailed Explanation of User Options:
Temperature Differential
(User Option 1 and 2)
Thedifferentialsettingisthetemperaturecontrolrangethatyourthermostat
willprovide.Thesmallerthesetting,thetighteryourrangeoftemperature
controlandcomfortwillbe.The2ndstagedifferentialisonlyforsystems
withasecondstageofheating(auxiliaryheat).
Temperature Adjustment
Presstheorbuttontoadjustthecurrentsetpointtemperature.
Status Indicators
Statusindicatorsappearinthedisplaytolet
youknowifyoursystemisheating,cooling
oroff.
HEAT ON Indicatesyourheatingsystemisrunning.
COOL ON Indicatesyourcoolingsystemisrunning.
Additional Status Indicators (Model 1220NC Only):
AUX Indicatesthattheauxiliarystageofheatingisrunning
 (Multi-StageSystemsonly).
EMER Indicatesthattheemergencyheatingsystemisrunning 
 (HeatPumpSystemsonly).
Resetting the Thermostat
Thisthermostatprovidesyouwitharesetbuttonthatwilleraseallofyour
usersettings.
Toresetthethermostat,useasmallobjectsuchasatoothpickorpaper-
clipandgentlypressthebuttonlocatedinsidethesmallholeonthefrontof
thethermostathousinglabeled“reset”.
7
Additional Operation Features
Compressor Protection
Thisthermostatincludesanautomaticcompressorprotectiondelayto
avoidpotentialdamagetoyoursystemfromshortcycling.Thisfeature
activatesashortdelayafterturningoffthesystemcompressor.
8
Thermostat Maintenance
Changing the Batteries
Dependingonyourparticularinstallation,this
thermostatmaybeequippedwithtwo(2)“AA”
typealkalinebatteries.
If batteries are installed and they become low,
a low battery indicator will appear in the display.
You shouldchangeyourbatteriesimmediately
whenyouseethelowbatterysignalbyfollowing
theseinstructions.

Braeburn 1020NC Specifications

General

Programmable	No
Stages	1 Heat/1 Cool
Terminals	R, C, W, Y, G
Hold Function	Yes
Filter Change Indicator	No
Type	Non-Programmable
Temperature Range	40°F to 90°F
Power Source	24 VAC
Display	Backlit LCD
Compatibility	Single Stage Heat/Cool Systems
Temperature Control	±1° F
