7 User Manual
Room Temperature .............................Displays the current room temperature
Set Temperature .................................Displays the current setpoint temperature
Outdoor Temperature .......................... If a Braeburn
®
outdoor sensor is connected, the
outdoor temperature will be displayed
Room Humidity (4235 only) ................. Displays the current room Relative Humidity level
Humidity Call Indicator (4235 only) ..... Indicates when there is a call for Humidification or
Dehumidification (in enabled)
Override Indicator ................................ Indicates that the current program schedule has
been temporarily overridden
Time of Day .......................................... Displays the current time of day
Message Center ................................... Displays various thermostat status and
maintenance information
System Mode ...................................... Displays the system mode and current system status
Fan Mode Indicator .............................. Indicates the current system fan mode
Fan Status Indicator ............................ Indicates that the system fan is running
Lock Mode Indicator ............................ Indicates if the thermostat is locked
Low Battery Indicator .......................... Indicates when the batteries need to be replaced
Thermostat Display
1
2
3
4
5
6
7
8
9
10
11
12
13
