65
FUNCTIONS
9) BATTERY CHARGING LAMP
It will be turned on when the key switch is put into the “ON”
position, and will be turned off when the battery starts being
charged after engine is started and the engine revolution in-
creases. The battery will not be charged with the engine below
1,000 rpm. (The rpm should be 1,500 rpm or higher)
10) FUEL EMPTY LAMP
It will light up when there is little fuel in fuel tank.
Refuel immediately as empty fuel tank may cause inhalation
of air.
11) TRANSMISSION WARNING LAMP
Transmission warning lamp will light up when trouble occurs
with shuttle or PTO or four-wheel driving part of transmission
part.
12) LIFT UP LAMP LAMP
Lift up lamp will light up when lift arm is lifted up by one-touch
moving up, or reverse moving up or turning increase to maxi-
mum position.
