Branson Sonifier 450 - Specifications

Chapter 5: Technical Specifications
Specifications
5 - 2 100-413-016 Rev. C
5.1 Specifications
5.1.1 Electrical Specifications
Table 5.1 Electrical specifications
Controls &
Displays
Timer: 0-15 Minutes and Hold
Output control: Duty Cycle Continuous
ON/OFF Switch
Pilot Light
Output control
Adjusts amplitude of power supply output voltage.
Range: 10% - 100% of nominal converter amplitude.
Duty Cycle
Intermittent-pulse duration adjustable 10% - 90%, 1
pulse per second.
Continuous Processing Time
Connector
RF: connects 20kHz, high voltage to converter con-
nections (Model 102C).
Horn
Frequency
19.850 - 20.050 kHz
Line Voltage
Model 250: 100-120V, 50/60 Hz, 2.0 A
200-245V, 50/60 Hz, 1.2 A
Model 450: 100-120V, 50/60 Hz, 4.0 A
200-245V, 50/60 Hz, 2.3 A
Fuse: 5A, 250V, 5x20mm, SB or TYPE T
Leakage: 0.5mA Maximum (115V line to ground)
Power
Minimum
acceptable
output power
Model 250, 150 Watts.*
Model 450, 350 Watts.*
