Appendix C Accessories
C - 4 100-413-016 Rev. C
C.5 Continuous-Flow Attachment
This attachment, which is screwed on to the disruptor horn, permits continuous
processing of low-viscosity materials at rates up to 38 liters per hour. Designed
primarily for emulsifying, dispersing and homogenizing, the attachment will dis-
rupt most cells, with the exception of the more difficult species. The materials
being treated may be passed through the attachment more than once to obtain
desired results. For cooling, a water jacket with input, output, and overlow con-
nections is provided.
C.6 Soundproof Box
Even though ultrasound is above the audible range of the human ear, mechanical
noise occurs when liquids are treated ultrasonically. The soundproof box reduces
this noise by 25 to 28 db. It is especially useful when the Sonifier is used for
extended periods of time.
Figure C.1 Soundproof Box
