Brasch GSE Generation 2 - Page 42

IOM01
Rev 1.0 – December 22, 2020 42
Figure 7: Relay Wiring Color Code
Zone 1 (TS2)
A1 COM
A1 NC
A2 NO
A2 COM
A2 NC
ALR COM
ALR NC
Yellow
Yellow
Brown
Brown
Gray
Gray
A1 COM
A1 NC
A2 NO
A2 COM
A2 NC
ALR COM
ALR NC
Red
Red
Blue
Blue
Purple
Purple
Zone 2 (TS3)
AC Input Wiring (TS1)
EARTH
NEUTRAL
LINE
Green
(120 VAC Only)
White
Black
Figure 8: Input Power Connections
