Page 13
Hydraulic Schematic
Roll Stop
Cylinder
Orifice
Pump Side
Cylinder
BACKUP
PUMP
2500
PSI
Secondary
Valve
Folding
Relief Valve
Lifting
Relief Valve
Down
Valve
1900
PSI
PUMP
Opposite
Pump
Cylinder
M
Orifice
Bridging
Valve
800
PSI
.50 GPM
Roll Stop Fold
Pressure Switch
Fixed Displacement
Pump
Vented Reservoir
Orifice
Backup Pump
Single Acting Cylinder
Check Valve
Manual
Shutoff Valve
Pressure Switch
2 Way 2 Position
Solenoid Valve
Pressure Compensated
Flow Control
Relief Valve
Description Symbol Description Symbol
Filter Screen
Unfold Orifice
M
Pump Motor
Hydraulic Port
