Series 6A Installation, Operation & Maintenance
Calibration & Commissioning
6A O & M : 17
41)YCUP Uppervaluefortight
closing
0.0 … 99.5 … 100% Used to set the value for tight “Tight closing below”
and “Tight closing above”. Factory setting is “99.5”
Normally
Open
Normally
Closed
Functions while in binary input mode.
OFF Factory setting.
on -on Binary message from peripherals
bloc1 Used to lock the configuration operation
bloc2
uP -uP
doWn -doWn
Actuator regulating to the valve specified by
parameters “YA” and “YE”
StoP -StoP Piezo valves are blocked. Actuator remains at last
position.
42)BIN12) FunctionofBE1
PST -PST Used to trigger a partial stroke test
Normally
Open
Normally
Closed
Functions while in binary input mode.
OFF Factory setting.
on -on Binary message from peripherals
uP -uP
doWn -doWn
Actuator regulating to the valve specified by
parameters “YA” and “YE”
StoP -StoP Piezo valves are blocked. Actuator remains at last
position.
43)BIN22) FunctionofBE2
PST -PST Used to trigger a partial stroke test
Normal Inverted
Off
44)AFCT3) AlarmFunction
Used to determine the value at which going above or
below a given offset or angle will result in a
message.
45)A1 Triggerthreshold,alarm1
0.0 … 10.0 … 100 %
46)A2 Triggerthreshold,alarm2
0.0 … 90.0 …100%
Used to specify when an alarm should be displayed.
Normal Inverted
47)FCT3) Functionforfault
messageoutput
Cannot be switched off. Can be suppressed by
switching to “No Automatic Mode”
48)TIM Monitoringtimefor
settingoffaultmessage
Auto / 0 … 100 Used to set the time in seconds that the positioner
must have reached the regulated condition.
49)LIM Responsethresholdfor
faultmessage
Auto / 0 … 100 Used to set a value for the permissible size of the
regulation device to trigger a fault message.
no
Strt
50)PRST Preset(factorysetting)
oCAY
Used to restore factory settings and reset
initialization. Press increment button for 5 seconds.
OFF
On1
On2
51)XDIAG Activationofextended
diagnostics
On3
Used to activate extended diagnostics.
FSVL Actuator controlled using the parameterization safety
point. Effective after a power failure.
FSSP Actuator controlled using the last effective set point
52)FSTY SafetySeating
FSAC Valves move to location based on spring force.
(Factory Defined)
