Series 6A Installation, Operation & Maintenance – Technical Data
6A O & M : 37
2. Optional Models
Technical specifications
1)
Only in conjunction with the basic device 6DR5...-.E.... Only T4 permissible when using with I
y
module.
Add-on modules Without Ex protection/
with Ex d protection
With Ex ia/ib protection With Ex n/dust protection
Ex protection acc. to ATEX – II 2G Ex ia/ib II C T4/T5/T6
1)
Ex n
II 3 G Ex nA nL[nL] IIC T6
Dust
II 3 D Ex tD A22 IP66 T100°C
Mounting location – Zone 1 Zone 2/22
Permissible ambient temperature for opera-
tion
(For devices with Ex protection: Only in con-
junction with the basic device 6DR5... -.E....
Only T4 permissible when using I
y
module.)
-30 ... +80 °C (-22 ... +176 °F) T4: -30 ... +80 °C (T4: -22 ... +176 °F)
T5: -30 ... +65 °C (-22 ... +149 °F)
T6: -30 ... +50 °C (-22 ... +122 °F)
Alarm unit 6DR4004-8A
Binary alarm outputs A1, A2 and alarm output
• Signal status High (not responded)
Signal status Low* (responded)
(* Low is also the status when the basic
device is faulty or has no electric power
supply)
Conductive, R = 1 kΩ, +3/1 %*
Disabled, I
R
< 60 µA
≥ 2.1 mA
≤ 1.2 mA
(* When used in the flameproof
enclosure the current consump-
tion must be limited to 10 mA
per output.)
(Switching threshold with supply to EN 60947-5-6: U
H
= 8.2 V,
R
i
= 1 kΩ)
• Internal capacitance C
i
– 5.2 nF 5.2 nF (at "nL")
• Internal inductance L
i
– Negligible
• Power supply U
H
≤ 35 V –
• Connecting to circuits with the following
peak values
– Intrinsically safe switching
amplifier to EN 60947-5-6
U
i
= 15.5 V DC
I
i
= 25 mA
P
i
= 64 mW
at "nA" and "tD":
U
n
= 15.5 V DC
at "nL":
U
i
= 15.5 V DC
I
i
= 25 mA
Binary input BE2
• Electrically connected to the basic device
- Signal status 0 Floating contact, open
Floating contact, closed
3 V, 5 mA
≤ 4.5 V or open
≥ 13 V
≥ 25 kΩ
- Signal status 1
- Contact load
• Electrically isolated from the basic device
- Signal status 0
- Signal status 1
- Natural resistance
• Static destruction limit
± 35 V –
• Internal inductance and capacitance – Negligible
• Connecting to circuits with the following
peak values
– Intrinsically safe U
i
= 25.2 V at "nA" and "tD":
U
n
= 25.2 V DC
at "nL":
U
i
= 25.2 V DC
Electrical isolation The 3 outputs, the input BE2 and the basic device are electrically isolated from each other
Test voltage 840 V DC, 1 s
