Series 6A Installation, Operation & Maintenance – Technical Data
6A O & M : 36
Technical specifications
SIPART PS2 Basic device
without Ex protection
Basic device
with Ex d protection
(flameproof enclosure)
Basic device
with Ex ia/ib protection
Basic device
with Ex n/
dust protection
Explosion protection ATEX - Ex d
II 2 G Ex d II C T6
Ex ia/ib
II 2 G Ex ia/ib II C T6
Ex n
II 3 G Ex nA nL[nL] IIC T6
Dust
II 3 D Ex tD A22 IP66
T100°C
Mounting location - Zone 1 Zone 2/22
Permissible ambient temperature for
operation
At ≤ -10 °C (+14 °F) the display refresh
rate of the indicator is limited.
(for basic devices with EX ia/ib and Ex n
protection the following applies: Only T4
is permissible when using I
y
module)
-30 ... +80 °C
(-22 ... +176 °F)
T4: -30 ... +80 °C (-22 ... +176 °F)
T5: -30 ... +65 °C (-22 ... +149 °F)
T6: -30 ... +50 °C (-22 ... +122 °F)
Electrical specifications
Input
2-wire connection (terminals 6/8)
Rated signal range 4 ... 20 mA
Current to maintain the auxiliary power
supply
≥ 3.6 mA
Required load voltage
U
B
(corresponds to Ω at 20 mA)
• Without HART (6DR50..)
- Typical 6.36 V
(corresponds to 318 Ω)
7.8 V
(corresponds to 390 Ω)
- max. 6.48 V
(corresponds to 324 Ω)
8.3 V
(corresponds to 415 Ω)
• Without HART (6DR53..)
- Typical 7.9 V
(corresponds to 395 Ω)
–
- max. 8.4 V
(corresponds to 420 Ω)
–
• With HART (6DR51..)
- Typical 6.6 V
(corresponds to 330 Ω)
–
- max. –
• With HART (6DR52..)
- Typical – 8.4 V
(corresponds to 420 Ω)
- max. – 8.8 V
(corresponds to 440 Ω)
• Static destruction limit ± 40 mA –
Internal capacitance C
i
• Without HART – 22 nF 22 nF (at "nL")
• With HART – 7 nF 7 nF (at "nL")
Internal inductance L
i
• Without HART – 0.12 mH 0.12 mH (at "nL")
• With HART – 0.24 mH 0.24 mH (at "nL")
For connection to circuits with the fol-
lowing peak values
– intrinsically safe
U
i
= 30 V DC
I
i
= 100 mA
P
i
= 1 W
at "nA" and "tD":
U
n
= 30 V DC
I
n
= 100 mA
at "nL":
U
i
= 30 V DC
I
i
= 100 mA
