5
(5) +
Hold these two buttons to show firmware version; A/D code or input
working voltage of indicator.
(6) +
Hold these two buttons to enter setting mode when the sealed calibration
switch is on.
(7) +
Hold these two buttons to enter calibration mode when the sealed
calibration switch is on.
3.3 In setting mode:
HOLD UNITS TARE OFF/ON
(1) Rotate the flashed position from right to left
(2) Change the digit on flashed position. The digit can be changed
to 0, 1, 2…9; and be flashed.
(3)
Confirm receiving and storing the displayed parameters,
After the setting of the las
t parameter, the indicator will
not exit the setup mode, and cycles from the first parameters
for viewing or modifications.
Exit from setting mode to normal work mode
3.4 In displaying A/D code or input voltage mode:
(1) No function
