SPECIFICATIONS
49
11 SPECIFICATIONS
11.1 Pump head
11.1.1 Performance
Description Bredel 10 Bredel 15 Bredel 20
Hose inner diameter [mm] 10 15 19
Max. capacity, continuous [m
3
/h] 0.11 0.38 0.62
Max. capacity, intermittent [m
3
/h]
*
* Intermittent duty: "Let the pump stand still to cool down for at least 1 hour after 2 hours of
operation".
0.16 0.60 1.09
Capacity per revolution [l/rev] 0.022 0.083 0.152
Permissible ambient temperature [°C] -20 to +45
Permissible product temperature [°C] -10 to +80
Sound level at 1 m [dB(A)] 60
Maximum working pressure [kPa]
Description Bredel 10 Bredel 15 Bredel 20
Rotor pressure
range
Low Medium High Low Medium High Low Medium High
Hose
type
NR 400 800 1200 400 800 1200 400 800 1000
NBR 400 800 1200 400 800 1200 400 800 1000
EPDM 400 800 1000 400 800 1000 400 800 1000
CSM 400 800 1000 400 800 1000 400 800 1000
