Bredel 10 - Parts list

SPECIFICATIONS
54
11.5 Parts list
11.5.1 Overview
Pos. Description
1 Cover assembly. Refer to § 11.5.2.
2 Pump head assembly. Refer to § 11.5.3.
3 Pump support assembly. Refer to § 11.5.4.
4 Barbed nipple assembly. Refer to § 11.5.5.
5 Threaded nipple assembly. Refer to § 11.5.6.
6 Flange assembly (1). Refer to § 11.5.8.
7 Flange assembly (2). Refer to § 11.5.7.
8 Lubricant. Refer to § 11.5.10.
